How to use IDEAL AIR Humidifier Heating & Cooling

Ideal-Air™ Pro Series Mini Split 24,000 BTU 16 SEER Heating & Cooling

Ideal-Air™ Pro Series 24,000 BTU 16 SEER Heating & Cooling Mini Split to include 1 indoor unit and 1 outdoor unit. These offer high-efficiency performance at 16 SEER. They have inverter compressor technology offering 30%–50% energy savings. The indoor evaporator unit can be easily installed with included wall mount bracket. Includes LCD screen hand-held programmable remote controller. Auto restart after power failure. Requires certified HVAC professional installation. Requires field-supplied electrical and communication wiring. A copper refrigerant line sold separately. The line set diameters are 3/8 in and 5/8 in, 208/230 V, 1 phase, 25 Amps, 2425 W, outdoor ambient operating range: (Cooling = 5°F to 122°F), (Heating = 5°F to 86°F).

Ideal-Air™ Pro Series Mini Split 36,000 BTU 16 SEER Heating & Cooling

Ideal-Air™ Pro Series 36,000 BTU 16 SEER Heating & Cooling Mini Split to include 1 indoor unit and 1 outdoor unit. These offer high-efficiency performance at 16 SEER. They have inverter compressor technology offering 30%–50% energy savings. The indoor evaporator unit can be easily installed with included wall mount bracket. Includes LCD screen hand-held programmable remote controller. Auto restart after power failure. Requires certified HVAC professional installation. Requires field-supplied electrical and communication wiring. A copper refrigerant line sold separately. The line set diameters are 3/8 in and 5/8 in, 208/230 V, 1 phase, 35 Amps, 3835 W, outdoor ambient operating range: (Cooling = 5°F to 122°F), (Heating = 5°F to 86°F).

Ideal-Air™ Commercial Grade Humidifier 75 Pints

This excellent quality humidifier features a multi-directional fogging head. The coverage is from 160–320 sq ft, depending on humidification requirements and ceiling height. Maximum output is 75 pints per day. Commercial-grade motor for years of use. Connects directly to your water supply with your own hookup (uses 1/4 in tubing). Operates at 62 dBA. Measures 12.2 in tall x 12.2 in diameter. 110 V/60 Hz/0.9 Amps. We recommend using a Titan Controls® Eos® 1 with this product!

Ideal-Air™ Industrial Grade Humidifier 200 Pints

This industrial-grade humidifier features a multi-directional fogging head. Coverage is from 1176–1614 sq ft, depending on humidification requirements and ceiling height. Maximum output is 200 pints per day. It has an industrial-grade motor for years of use. Connects directly to your water supply with your own hookup (uses 1/4 in tubing). Operates at 62 dBA. Measures 15 in tall x 15 in diameter. 110 V/60 Hz/0.9 Amps. We recommend using a humidity controller such as a Titan Controls® Eos® 1 with this product.

Ideal-Air™ Dehumidifiers 22, 30 & 50 Pint


The Ideal-Air Dehumidifiers offer quick maintenance with easy filter access and a filter that is removable and washable. It is mobile and easy to move with built in handles and wheels. These units also have low temperature defrosting and an easy-to-use LED display panel. Removable water tank with an automatic shutoff when the reservoir is full. Can be plumbed for permanent drainage.

​​​​​​​

The Ideal-Air Dehumidifiers are now rated at AHAM standards (80°F, 60% Relative Humidity).

  • The 22 Pint Dehumidifier is 4.0 Amps / 420 Watts, 115 Volt, with a reservoir capacity of 3 liters.
  • The 30 Pint Dehumidifier is 4.7 Amps / 520 Watts, 115 Volt, with a reservoir capacity of 3 liters.
  • The 50 Pint Dehumidifier is 6.9 Amps / 720 Watts, 115 Volt, with a reservoir capacity of 6 liters.

Ideal-Air™ Pro Series Dehumidifier 60 Pint

Ideal-Air™ Pro Series 60 Pint Dehumidifier has automatic restart if power is lost. Easy-to-use digital display humidity readings, internal condensate pump, removable washable filter, 1 speed fan motor, powder-coated metal casing for long life and a heavy-duty compressor. Built-in defrost that is designed for operation down to 41°F. Set upright on their feet for 3 hrs prior to use. 60 pint unit: Temp. Range: 41°F–95°F, condensation removal: (24 hrs) 60 pints (86°F, 80% RH); Power: 4.6 Amps/520 W; Supply Voltage: 115 V - 1 Phase - 60 Hz; R410A. Ideal-Air™ recommends that dehumidifiers use surge protectors and a dedicated electrical circuit. In the event of a power failure, a spike in voltage may occur when the power is reinstated. This can damage the circuit board, which is not covered under warranty.

Ideal-Air™ Pro Series Dehumidifier 100 Pint

Ideal-Air™ Pro Series 100 Pint Dehumidifier has automatic restart if power is lost. Easy-to-use digital display humidity readings, internal condensate pump, removable washable filter, 1 speed fan motor, powder-coated metal casing for long life and a heavy-duty compressor. Built-in defrost that is designed for operation down to 41°F. Set upright on their feet for 3 hrs prior to use. 100 pint unit: Temp. Range: 41°F–95°F, condensation removal: (24 hrs) 100 pints (86°F, 80% RH); Power: 6.75 Amps/728 W; Supply Voltage: 115 V - 1 Phase - 60 Hz; R410A. Ideal-Air™ recommends that dehumidifiers use surge protectors and a dedicated electrical circuit. In the event of a power failure, a spike in voltage may occur when the power is reinstated. This can damage the circuit board, which is not covered under warranty.

Ideal-Air™ Pro Series Dehumidifier 180 Pint

Ideal-Air™ Pro Series 180 Pint Dehumidifier has automatic restart if power is lost. Easy-to-use digital display humidity readings, internal condensate pump, removable washable filter, 1 speed fan motor, powder-coated metal casing for long life and a heavy-duty compressor. Built-in defrost that is designed for operation down to 41°F. Set upright on their feet for 3 hrs prior to use. 180 pint unit: Temp. Range: 41°F–95°F, condensation removal: (24 hrs) 180 pints (86°F, 80% RH); Power: 12.31 Amps/1350 W; Supply Voltage: 115 V - 1 Phase - 60 Hz; R410A. Ideal-Air™ recommends that dehumidifiers use surge protectors and a dedicated electrical circuit. In the event of a power failure, a spike in voltage may occur when the power is reinstated. This can damage the circuit board, which is not covered under warranty.

Ideal-Air™ Pro Series Ultra Sonic Humidifier 150 Pint

The Ideal-Air™ Pro Series Ultra Sonic Humidifier is designed with ultra-sonic transducers to supply ultra-fine water particles. This is to help form a more balanced humidity field over your plant's entire canopy. Ideal-Air™ Pro Series Ultra Sonic Humidifier plates are made from cold-rolled steel and a stainless steel box with a standard water inlet with overflow safety switch, reservoir drain outlet, sediment filter, LED display and humidity control (30%–90%). This unit is designed to produce up to 150 pints per day of ultra-fine mist. 115 V, 60 Hz and 2.7 Amps. We recommend all Ultra Sonic Humidifiers be ducted, using 4 in PVC or 4 in DWV plastic pipe works best. Units should not be run without ducting or the top of the unit may be covered in water and shut off. Please don’t fill the unit through the discharge piping outlets. Doing this will overfill the tank and prevent the unit from creating humidity. The unit should only be filled through the provided hose and float valve to ensure proper water level and correct operation.

Ideal-Air™ Pro Series Ultra Sonic Humidifier 300 Pint

The Ideal-Air™ Pro Series Ultra Sonic Humidifier is designed with ultra-sonic transducers to supply ultra-fine water particles. This is to help form a more balanced humidity field over your plant's entire canopy. Ideal-Air™ Pro Series Ultra Sonic Humidifier plates are made from cold-rolled steel and a stainless steel box with a standard water inlet with overflow safety switch, reservoir drain outlet, sediment filter, LED display and humidity control (30%–90%). This unit is designed to produce up to 300 pints per day of ultra-fine mist. 115 V, 60 Hz and 7.8 Amps. We recommend all Ultra Sonic Humidifiers be ducted, using 4 in PVC or 4 in DWV plastic pipe works best. Units should not be run without ducting or the top of the unit may be covered in water and shut off. Please don’t fill the unit through the discharge piping outlets. Doing this will overfill the tank and prevent the unit from creating humidity. The unit should only be filled through the provided hose and float valve to ensure proper water level and correct operation.

Ideal-Air™ Pro Series Ultra Sonic Humidifier 600 Pint

The Ideal-Air™ Pro Series Ultra Sonic Humidifier is designed with ultra-sonic transducers to supply ultra-fine water particles. This is to help form a more balanced humidity field over your plant's entire canopy. Ideal-Air™ Pro Series Ultra Sonic Humidifier plates are made from cold-rolled steel and a stainless steel box with a standard water inlet with overflow safety switch, reservoir drain outlet, sediment filter, LED display and humidity control (30%–90%). This unit is designed to produce up to 600 pints per day of ultra-fine mist. 115 V, 60 Hz and 10.3 Amps. We recommend all Ultra Sonic Humidifiers be ducted, using 4 in PVC or 4 in DWV plastic pipe works best. Units should not be run without ducting or the top of the unit may be covered in water and shut off. Please don’t fill the unit through the discharge piping outlets. Doing this will overfill the tank and prevent the unit from creating humidity. The unit should only be filled through the provided hose and float valve to ensure proper water level and correct operation.
